10A~100A, 12V/24V Auto., USB, LCD, PWM Solar Charger Controller

1 / 5

10A~100A, 12V/24V Auto., USB, LCD, PWM Solar Charger Controller

Customization:	Available
Condition:	New
Application:	Collector Controller, Solar System Controller, Charger Controller, Lighting Controller, Wind Controller, Solar Working Station, Voltage Controller, Thermal Controller

Send Inquiry

Product Description

Basic Specifications

Model NO.

10A~100A, 12V/24V auto., PWM

Rated Voltage

12V/24V Auto.

Package

Standard Export Packing

Specification

10A~100A, 12V/24V auto., PWM

HS Code

8537109090

Capacity

1000000PCS/Year

Product Overview

TK series solar charge controller is a new series of high cost performance product. The controller with high reliability, accuracy of sampling and full electronic protection. PWM multi stages charging makes them more efficiency and better charging. They are with LCD display, all working data programmable. Through optional communication function (RS232 or RS485), users are able to remote monitoring and setting the system parameters.

★

Key Features

✔ PWM charging technology

✔ Multistage charging (Bulk, Absorption, Float, Equalized)

✔ Precise voltage regulation

✔ Automatic detection of system voltage

✔ Automatic load reconnection

✔ Multiple load controlling modes

✔ Automatic temperature compensation

✔ Adaptable to Sealed, Gel, and Flooded batteries

✔ Preset parameters for charging & discharging

✔ Optional communication function

🛡

Electronic Protection

Over charge & discharge protection

Over temperature & load protection

Automatic electronic fuse

Short circuit protection (Load & PV)

Input over voltage protection

Reverse current protection at night

Reverse connection protection (PV, Load, Battery)

📊

Visual Display & Interface

Vivid LCD graphic symbols present working status and related parameters explicitly.

Frequently Asked Questions

What is the advantage of the PWM multistage charging?

The TK series uses multistage charging (Bulk, Absorption, Float, and Equalized) to optimize charging efficiency, prevent battery overheating, and significantly extend the overall battery lifespan.

Does the controller support both 12V and 24V systems?

Yes, the controller features automatic voltage detection, allowing it to identify and work with both 12V and 24V battery systems seamlessly.

Can I monitor the system data remotely?

Remote monitoring is possible via the optional RS232 or RS485 communication ports, which allow users to set and check system parameters from a distance.

What types of batteries are compatible?

This controller is highly adaptable and can be used with Sealed, Gel, Flooded, and other customized battery types with preset or adjustable parameters.

How does the automatic temperature compensation work?

The controller adjusts the charging voltage based on the ambient temperature to ensure the battery is charged safely and efficiently in various environmental conditions.

What kind of load controlling modes are available?

It supports various modes including light control, time & light control, and normal mode, making it suitable for street lights or standard off-grid power systems.
